#include <Wire.h>

#define latchPin 11 // SR Latch Pin 12 Digital pin
#define clockPin 9 // SR Clock Pin 11 Digital pin
#define dataPin 12 // SR Pin 14 PWM pin


int ones = 0;
int ones_hex = 0;
int tens = 0;
int tens_hex = 0;
int hundreds = 0;
int hundreds_hex = 0;
int thousands = 0;
int thousands_hex = 0;

int total = 0;

int LCD_Position[10]={
  0xfc,
  0x60,
  0xda,
  0xf2,
  0x66,
  0xb6,
  0xbe,
  0xe0,
  0xfe,
  0xe6  };

void split(int input_number){  // splits and writes the 4 didgit number to the
                               // ones, tens, hundreds, and thousands variables

Serial.print("Input Number ");
Serial.println(input_number);

thousands = int(input_number/1000);

Serial.print("Thousands ");
Serial.println(thousands);

hundreds = int(input_number/100);

hundreds = hundreds-(int(hundreds/10)*10);

Serial.print("Hundreds #2 ");
Serial.println(hundreds);

tens = int(input_number/10);

tens = tens-(int(tens/10)*10);
Serial.print("Tens #2 ");
Serial.println(tens);

ones = input_number-(int(input_number/10)*10);
Serial.print("Ones ");
Serial.print(ones);
Serial.println("   ");

}

void zero_out(){
  //start by blanking the LEDS
    digitalWrite(latchPin, LOW);
  //Shifts data to highbyte second digit
  //You change the d1 to d4 to low to activate
    shiftOut(dataPin, clockPin, LSBFIRST, 0x00);
  //Shifts data to lowbyte, number 7 with decimal point
    shiftOut(dataPin, clockPin, LSBFIRST, 0x00);
    digitalWrite(latchPin, HIGH);
    delay(2000);
}


void setup() {
  Serial.begin(9600);
  pinMode (latchPin,OUTPUT);
  pinMode (dataPin,OUTPUT);
  pinMode (clockPin,OUTPUT);



}

void loop() {
  //Shifts data to highbyte second digit
  //You change the d1 to d4 to low to activate
  //ABCD0000
  //A is first LED Left most or thousands
  //B is second LED Left Middle or hundreds
  //C is third LED Right Middle or tens
  //D is fourth LED Right most or ones


  zero_out();

  for(int count = 0; count<10; count++){
  //A is first LED Left most or thousands will be 7
  //0111 0000 is thousands
    digitalWrite(latchPin, LOW);
  //Shifts data to highbyte second digit
  //You change the d1 to d4 to low to activate
    shiftOut(dataPin, clockPin, LSBFIRST, 0x70);
  //Shifts data to lowbyte, number 7 with decimal point
    shiftOut(dataPin, clockPin, LSBFIRST, LCD_Position[count]);
    digitalWrite(latchPin, HIGH);
    delay(250);
  }


  for(int count = 0; count<10; count++){
  //B is second LED Left Middle or hundreds
  //1011 0000 is hundreds
    digitalWrite(latchPin, LOW);
  //Shifts data to highbyte second digit
  //You change the d1 to d4 to low to activate
    shiftOut(dataPin, clockPin, LSBFIRST, 0xb0);
  //Shifts data to lowbyte, number 7 with decimal point
    shiftOut(dataPin, clockPin, LSBFIRST, LCD_Position[count]);
    digitalWrite(latchPin, HIGH);
    delay(250);
  }


  for(int count = 0; count<10; count++){
  //C is third LED Right Middle or tens
  //1101 0000 is tens
    digitalWrite(latchPin, LOW);
  //Shifts data to highbyte second digit
  //You change the d1 to d4 to low to activate
    shiftOut(dataPin, clockPin, LSBFIRST, 0xd0);
  //Shifts data to lowbyte, number 7 with decimal point
    shiftOut(dataPin, clockPin, LSBFIRST, LCD_Position[count]);
    digitalWrite(latchPin, HIGH);
    delay(250);
   }


  for(int count = 0; count<10; count++){
  //D is fourth LED Right most or ones
  //1110 0000 is ones
   digitalWrite(latchPin, LOW);
  //Shifts data to highbyte second digit
  //You change the d1 to d4 to low to activate
    shiftOut(dataPin, clockPin, LSBFIRST, 0xe0);
  //Shifts data to lowbyte, number 7 with decimal point
    shiftOut(dataPin, clockPin, LSBFIRST, LCD_Position[count]);
    digitalWrite(latchPin, HIGH);
    delay(250);
  }


  // write A and B to 7
  //0011 0000 is A and B with 7
    digitalWrite(latchPin, LOW);
  //Shifts data to highbyte second digit
  //You change the d1 to d4 to low to activate
    shiftOut(dataPin, clockPin, LSBFIRST, 0x30);
  //Shifts data to lowbyte, number 7 with decimal point
    shiftOut(dataPin, clockPin, LSBFIRST, 0xe0);
    digitalWrite(latchPin, HIGH);
    delay(250);

zero_out();

  // write A and C to 7
  //0101 0000 is A and C with 7
  //1110 0000 is 7
    digitalWrite(latchPin, LOW);
  //Shifts data to highbyte second digit
  //You change the d1 to d4 to low to activate
    shiftOut(dataPin, clockPin, LSBFIRST, 0x50);
  //Shifts data to lowbyte, number 7 with decimal point
    shiftOut(dataPin, clockPin, LSBFIRST, 0xe0);
    digitalWrite(latchPin, HIGH);
    delay(250);


zero_out();

  // write A and D to 7
  //0110 0000 is A and D with 7
  //1110 0000 is 7
    digitalWrite(latchPin, LOW);
  //Shifts data to highbyte second digit
  //You change the d1 to d4 to low to activate
    shiftOut(dataPin, clockPin, LSBFIRST, 0x60);
  //Shifts data to lowbyte, number 7 with decimal point
    shiftOut(dataPin, clockPin, LSBFIRST, 0xe0);
    digitalWrite(latchPin, HIGH);
    delay(250);



}
